AutoCAD Planning & 2D Drafting

Learn foundational and advanced 2D drafting methods in AutoCAD. This course covers geometry planning, dimension rules, layer controls, and municipal blueprint layouts for architectural approval.

DET // ARCH_03

DET // ARCH_02

MAIN // STRUCT_01SCALE 1:25

Core Competencies & Outputs

Municipal Approval Standards
Bar Bending Drafting
Viewport Scaling
Command Optimization

Software & Professional Standards

AutoCAD 2DDrafting commandsSheet Set Manager

Course Modules & Syllabus

Module 01

Drafting Essentials

Mastering precise coordinate entry systems, drawing tools, modifications, dimensions, blocks, dynamic constraints, and template configurations.

Module 02

Submission Plans

Learning layout standards for building permissions, drafting site plans, detailed floor plans, sections, and structural framing layouts.

Module 03

Advanced Sheet Printing

Configuring AutoCAD layouts, setting up viewport scales, configuring plot styles (CTB), and creating professional title block templates.

Featured Case Studies

Explore live structural engineering, architectural, and estimation projects executed by our consultancy.

Almaspet Apartment, Kadapa

Residential Apartment (131,000 SFT) — Complete structural analysis, seismic design, and foundation sizing.

Chinna Chowk Apartment, Kadapa

Residential Apartment (88,990 SFT) — Reinforced concrete structural design, frame modeling, and detailing.

7-Roads Commercial Building, Kadapa

Commercial Building (45,550 SFT) — Bylaw-compliant architectural planning, spatial mapping, and municipal submission set preparation.

Srinivas Nagar G+4 Building, Kadapa

Residential Project Supervision (24,000 SFT) — Daily concrete pour supervision, rebar layout verification, and billing audits.

Cooperative Colony Duplex, Kadapa

Premium Villa Inspection (4,500 SFT) — Phase-wise foundation, column alignment, slab reinforcement audits.

Elevate your structural engineering career

Reserve your seat in our structural design and drafting master class modules. Internships are available with hand-on work on live project blueprints.
