3-DElevations

We create high-quality 3D elevations that bring your designs to life with clarity and precision. From concept to presentation, we craft visuals that communicate design intent and leave a lasting impact.

Explore Our Work
Primary showcase
Secondary detail
Tertiary details

Integrated Engineering Scope

We apply advanced software tools and certified standards to ensure our outputs meet municipal code limits, aesthetic ratios, and material efficiency benchmarks.

Core Competencies

Day/Night Scene Renders
High-Resolution Texturing
Landscape Integration
Facade Articulation

Digital Engineering Stack

Inspection of calculation models, detailing rules, and code compliance workflows.

Day/Night Scene Renders

Rendering high-fidelity daytime facades with natural skybox HDRI lighting, and night-time settings featuring warm LED light cones, step lights, and wall washing effects.

┌ EQUATION VETTING //
Exposure Value (EV) = log2(N^2 / t)
Day EV = 13
Night EV = 5

Vetted Parameters

Render EngineV-Ray / Corona / Lumion
Resolution Target4K UHD (3840x2160 pixels)
Day Sky BoxHigh-dynamic range HDRI sky dome
Light ProfilingIES profile dynamic lighting

High-Resolution Texturing

Mapping Physically Based Rendering (PBR) texture files onto building facade layers, including cement plaster, wooden slats, brick walls, and reflective double-glazed structural glass.

┌ EQUATION VETTING //
Fresnel Reflection (R) = R0 + (1 - R0) * (1 - cos(theta))^5

Vetted Parameters

Material FormatPBR (Physically Based Rendering)
Map ChannelsDiffuse, displacement, normal, roughness
Glass RefractionIOR set to 1.52 (Standard glass)
Material ScalingAccurate real-world coordinates

Landscape Integration

Modeling site topography context, planning boundary wall elevations, compound gate details, vehicle driveways, and planting shrubs and trees to preview final curb appeal.

┌ EQUATION VETTING //
Slope Ratio = H_ground_delta / Length_run <= 1:12 Ramp Limit

Vetted Parameters

Terrain ModelSlab height matching site topography
Vegetation ClassNative foliage libraries (low-poly models)
Driveway RampSlope limit max 1:12 angle
Entourage Assets3D human figures and vehicles

Facade Articulation

Modeling balconies, geometric relief details, pergolas, and vertical louvers to block solar heat while creating visual depth on building faces.

┌ EQUATION VETTING //
Shading Depth = d_overhang * cos(solar_elevation)

Vetted Parameters

Overhang LimitExtended up to 1.2m cantilevers
Louver MaterialAluminum section / WPC timber slats
Grooving Spacing10mm v-grooves in plaster zones
Visual Depth FocusAlternating projections and recesses

From concept design to construction delivery.

A step-by-step structural roadmap showing how we collaborate with you to deliver certified, high-performance architectural engineering.

01

Initial Inquiry & Alignment

You connect with our studio. We hold a structured consultation to outline your programmatic requirements, aesthetic vision, budget limits, and timeline goals.

02

On-Site Assessment & Mapping

Our engineers and designers visit the site to survey topography, assess existing load pathways, analyze solar paths, and evaluate local municipal zoning requirements.

03

Feasibility Study & Workflow Planning

We model structural wind, soil, and seismic codes to determine load capacity boundaries and architectural constraints before sketching any walls.

04

Conceptual Design & 3D Modeling

Our architectural team designs preliminary layouts, floor plans, and digital 3D volumetric models, exploring space relationships and massing aesthetics.

05

Detailed Structural Calculations

Our structural engineers calculate exact force models, sizing timber beams, concrete footings, and structural steel framing for certified building safety.

06

Client Feedback & Material Integration

We walk you through detailed blueprint files and spatial renders, integrating feedback on final materials, custom window orientations, and interior fixtures.

07

Zoning Submission & Permitting

We compile, stamp, and submit certified structural plans, environmental packages, and site drawings to local building departments for formal permit sign-off.

08

Construction Kickoff & Inspections

Builders break ground on site. Our engineers conduct regular phase-gate site inspections to confirm physical construction matches our precision schematics.
